CCBoot - iSCSI Boot Windows Diskless

CCBoot Features

• Boot Windows XP, Windows 2003, Vista, Windows 7 and Windows 2008 from iSCSI storage/target.
• Inside DHCP, gPXE, TFTP, Image Upload and iSCSI Target. It's all-in-one solution for iSCSI boot.
• Support physical drive, volume drive and VMWare disk file.
• Support upload boot image to the server and save with VMDK format.
• Clients can recovery to a new clear system after reboot.
• Clients can keep own system data after reboot.
• Support image read cache and client write-back cache.
• Support RAM cache with huge memory access (AWE).
• Support SSD cache.
• Support multiple servers, multiple NICs and load balance.
• Support multiple disks.
• Support client write cache.
• Support one image compatible with different devices (PnP).

System Requirements

• Server Requirements
  1. Windows 2000, Windows XP, Windows 2003, Vista or Windows 2008.
  2. Latest service packs should be installed on the server.
• Client Requirements
  1. Windows XP, Windows 2003, Vista, Windows 7 or Windows 2008.
  2. PXE 2.x compliant network adapter

Recommended Server Hardware

25 clients	CPU: 1.7G RAM: 2G System Image Disk: SATA HDD 120G Game Disk: RAID with 2 SATA HDD Client Write-back Disk: SATA HDD 120G Main Board: With SATA support Network: 100Mb Ethernet
50 clients	CPU: 2G RAM: 4G System Image Disk: SATA HDD 120G Game Disk: RAID with 2 STAT HDD Client Write-back Disk: 2 SATA HDD 120G Main Board: With RAID support Network: 1000Mb Ethernet
100 clients	CPU: 2.8G RAM: 8G System Image Disk: RAID with 2 SATA HDD Client Write-back Disk: 4 SATA HDD Main Board: With RAID support Network: 1000Mb Ethernet, 2 - 3 NICs
> 100 clients	Using multiple servers and load balance.
